Aluminum is an excellent material for conveyor beams thanks to its tensile strength, density, formability, weldability, and corrosion resistance.
HI FLEX conveyor system made of aluminum forms a cost-efficient, robust and lightweight basis for the transport of cargo in any stage of manufacture.
The entire conveyor system can easily be adapted if the production requirements are changed.
| Beam Width (mm) | 65 mm |
|---|---|
| Chain Width (mm) | 63 mm |
| Min. turning radius (mm) | 150 mm |
| Chain weight (plain) (kg/m) | 0.6 kg/m |
| Max. item weight (horizontal) (kg) | 10 kg |
| Max. item weight (vertical) (kg) | 2 kg |
| Max. weight on conveyor (kg) | 100 kg |
| Max. conveyor length (m) | 20 m |
| Standard conveyor speed (m/min) | 3~60 m/min |
| Working temperature (℃) | < 60℃ |
| Beam Width (inch) | 2.56" |
|---|---|
| Chain Width (inch) | 2.48" |
| Min. turning radius (inch) | 5.9" |
| Chain weight (plain) (lb/ft) | 0.408 lb/ft |
| Max. item weight (horizontal) (lb) | 22 lb |
| Max. item weight (vertical) (lb) | 4.4 lb |
| Max. weight on conveyor (lb) | 220 lb |
| Max. conveyor length (ft) | 65.6 ft |
| Standard conveyor speed (ft/min) | 10~200 ft/min |
| Working temperature (℉) | < 140℉ |
